• Schematic Image 7370001
  • Summit S-670 LP SS (2012) (USA/Canada)
  • 7370001

Additional Parts

Seq Part # Description Available Online
A 56701 Assembly guide, Summit E/S-670 '11, US/E
W 84280 Hardware kit, Summit '11
B 56202 Literature kit, Summit 670 LP '11, US/ES/F OBS
A 56826 Addendum for Mexico (Required for Mexico only)
1 70302 Hinge pin/cotter pin kit
2 66513 Logo plate, SS
2 66380 Lid assembly, SS, Summit 600 series
3 67088 Thermometer, '18
4 67717 Bezel for Genesis/Summit, '07
5 70369 Handle with bezels/spacers/hardware, Summit 600 series Shop Now$42.99
5 65908 Hardware pack for handle
6 69273 Handle light
7 65579 Rotisserie motor, Type B, '15
8 66339 Tuck away rotisserie bracket
8 70888 Plastic latch w/spring
9 70190 Warming rack, Summit 600 '07 Shop Now$47.99
10 67552 Set of stainless steel grates, Summit 640/650/660/670 Shop Now$301.99
10 70372 Rod-style grate, SS, 11.8", qty. 1
11 70375 Flavorizer bars, SS, set of 4
11 67670 Stainless steel flavorizer bars, full set, Summit 640/650/660/670 Shop Now$95.99
12 70306 Single burner tube for main burner, Summit '07, qty 1
12 67558 Burner tube kit, Summit 660/670
13 62773 Hardware for table assembly, Genesis 300 series, '11
13 66321 LHS table assembly, SS '17
14 81803 Small hardware pack
14 70312 LHS tool holder with hardware
15 88067 Manifold hardware, Summit '07
15 79175 LP manifold assembly, Summit 670/Summit Grill Center
16 70189 Momentary light switch, Summit '11
16 70882 Wiring harness, Summit 670
17 88231 Hardware kit for control panel, Summit '11
17 66328 Control panel, SS, Summit 670/Grill Center '17
18 88208 Hardware for bezels/control panel
18 70883 Small bezel w/fasteners, Summit 470/670
19 70378 Control knob for IR burner/smoker burner, qty 1 Shop Now$10.99
20 91538 Lighted control knob assembly, qty 2 (2012 and later models)
20 70867 Lighted control knob assembly, qty. 2 (pre-2012 models) Shop Now$29.99
20 67692 Control Knob Kit, Summit 660/670 Shop Now$74.99
21 88208 Hardware for bezels/control panel
21 70318 Bezel for main burners with hardware
22 70868 Sear knob assembly Shop Now$13.99
23 70880 Battery pack housing
23 70879 Battery pack head
24 70874 Heat shield/water baffle, Summit 670
24 88210 Hardware for burner tubes, Genesis/Summit '07
25 6498 Drip pan (qty 10) Shop Now$11.99
26 70113 Grease tray, Summit 600 '11, SS
27 70379 Catch pan kit
28 88063 Hardware for tank blocker
28 70322 Tank blocker (catch pan holder), Summit 600 series
29 91357 Door magnet
29 66335 LHS door assembly, SS, Summit S-600 '17
29 62779 Hardware for control panel, Genesis '11
30 70327 Door handles with hardware Shop Now$43.99
31 66274 RHS door assembly, SS, Summit S-600 '17
31 62779 Hardware for control panel, Genesis '11
31 91357 Door magnet
32 70981 LHS frame assembly, Summit '11, US
32 70332 Adjustable door hinge
33 91318 Bottom panel, Summit Platinum 6 burner LP, '10
33 67762 Hardware kit for bottom panel
34 43291 IR Burner black plastic tubing/wire wrap, Summit '14
34 70392 Hardware for IR cover
34 67513 IR cover, Summit 6 burner, black
35 70384 LP Orifice for IR burner, with nut, 30mb
35 70389 IR burner with bracket
36 70338 Cover box for IR burner
37 70390 Thermocouple with electrode and wire
37 20201822 Thermocouple nut
38 20201822 Thermocouple nut
38 70390 Thermocouple with electrode and wire
39 70398 Gas line for IR burner, 64"
40 80647 Rotisserie shaft, Summit E/S 600 series, '12
40 70380 Screws for rotisserie forks, qty 4
40 84116 Rotisserie hardware for tuckaway rotisserie, w/forks, '10
41 70373 Rod-style grate, SS, 8.1", qty. 1
42 70381 Smoker box assembly
43 70187 Chipper grate, Summit '07 smoker
44 70307 Smoker burner tube, Summit '07
45 70866 Sear burner tube kit, Summit 670
46 81252 Rubber lid bumper for side burner (Qty 1)
46 91175 Side burner cap, Summit '03
46 70396 LP side burner assembly, Summit '07
46 91174 Ignition assembly for side burner Shop Now$26.99
46 67765 Hardware for side burner table, Genesis
46 91173 Side burner ring
46 30125801 Control knob, side burner, grey
47 64847 Cookbox, Summit 660/670 '13
47 60600 Hardware for cookbox, Summit '10
47 70339 Silicone bumpers, quantity 4
47 64849 Flavor bar brackets Summit cookbox 6 burner
48 70344 LP bulkhead assembly
48 88212 Hardware for bulkhead, Summit '07
49 70309 Corrugated gas line, main, Summit 600 series
50 66463 Side burner lid w/hardware, Summit '17
50 67764 Hinge rod and clip for side burner lid, Genesis '07
51 66322 Side burner table assembly, SS '17
51 62773 Hardware for table assembly, Genesis 300 series, '11
52 65909 QCC1 hose and regulator, 30" Shop Now$34.99
53 81803 Small hardware pack
53 70349 RHS tool holder with hardware
54 70371 Transfer line for side burner
55 70351 Frame connector and hardware, Summit 6 burner
55 62776 Hardware for frame/rear panel, Genesis '11
56 70354 Rear panel, LP Summit 600 series
57 70982 RHS frame assembly, Summit LP '11, US
57 70332 Adjustable door hinge
58 70199 Tank scale assembly with magnet, '11
59 88229 Hardware kit for LED sensor, Summit '11
59 70983 LED display and sensor, Summit '11
60 88065 Glide buttons and hardware
61 81544 Match holder
62 70359 Caster w/o lock, Spirit ('09-'12), Genesis/Summit ('07-'11) qty 1 Shop Now$21.99
63 70360 Locking caster, Spirit ('09-'12), Genesis ('07-'11) Summit ('07-'11) qty 1 Shop Now$21.99
410 56701 Assembly guide, Summit E/S-670 '11, US/E
410 56202 Literature kit, Summit 670 LP '11, US/ES/F OBS
470 67762 Hardware kit for bottom panel
470 70392 Hardware for IR cover
470 84280 Hardware kit, Summit '11
470 88067 Manifold hardware, Summit '07
470 88211 Retainer clip for thermocouple/wires
470 88231 Hardware kit for control panel, Summit '11
470 62776 Hardware for frame/rear panel, Genesis '11
470 67765 Hardware for side burner table, Genesis
470 84116 Rotisserie hardware for tuckaway rotisserie, w/forks, '10
470 88065 Glide buttons and hardware
470 88210 Hardware for burner tubes, Genesis/Summit '07
470 88229 Hardware kit for LED sensor, Summit '11
470 60600 Hardware for cookbox, Summit '10
470 67764 Hinge rod and clip for side burner lid, Genesis '07
470 81803 Small hardware pack
470 88063 Hardware for tank blocker
470 88208 Hardware for bezels/control panel
470 88212 Hardware for bulkhead, Summit '07
480 91174 Ignition assembly for side burner Shop Now$26.99
480 70379 Catch pan kit
510 6498 Drip pan (qty 10) Shop Now$11.99
510 7421 Weber Original Gourmet BBQ System Griddle Shop Now$44.99
510 7615 Weber Elevations Tiered Cooking System Grill Rack and Skewer Set
510 7618 Weber Elevations Tiered Cooking System 4-Piece Skewer Set
510 8836 Weber Original Gourmet BBQ System Pizza Stone Shop Now$44.99
510 7404 Griddle for Summit E/S 420/670 Shop Now$79.99
510 7585 Gourmet BBQ System Cooking Grate, Summit series Shop Now$119.99
510 7617 Weber Elevations Tiered Cooking System Expansion Rack Shop Now$13.99
510 8834 Weber Original Gourmet BBQ System Sear Grate Shop Now$44.99
510 8841 Weber Original Gourmet BBQ System Ebelskiver - discontinued
510 7109 Cover, Summit 600 series Shop Now$89.99
510 7577 Weber Style Premium Cast-Iron Plancha Summit 400/600 Series
510 7616 Weber Elevations Tiered Cooking System Basket with Frame
510 7627 QCC1 hose and regulator, 30" Shop Now$34.99
510 8838 Weber Original Gourmet BBQ System Poultry Roaster Shop Now$54.99
