A
|
56765
|
Literature kit, Summit 670 '11, GB
|
|
|
B
|
62776
|
Hardware for frame/rear panel, Genesis '11
|
|
|
B
|
67765
|
Hardware for side burner table, Genesis
|
|
|
B
|
84280
|
Hardware kit, Summit '11
|
|
|
B
|
88067
|
Manifold hardware, Summit '07
|
|
|
B
|
88212
|
Hardware for bulkhead, Summit '07
|
|
|
B
|
60600
|
Hardware for cookbox, Summit '10
|
|
|
B
|
67764
|
Hinge rod and clip for side burner lid, Genesis '07
|
|
|
B
|
84116
|
Rotisserie hardware for tuckaway rotisserie, w/forks, '10
|
|
|
B
|
88066
|
Tank glide buttons and hardware, export
|
|
|
B
|
88210
|
Hardware for burner tubes, Genesis/Summit '07
|
|
|
A
|
56766
|
Assembly guide, Summit 670 '11, UK
|
|
|
B
|
67762
|
Hardware kit for bottom panel
|
|
|
B
|
70392
|
Hardware for IR cover
|
|
|
B
|
88063
|
Hardware for tank blocker
|
|
|
B
|
88208
|
Hardware for bezels/control panel
|
|
|
B
|
88231
|
Hardware kit for control panel, Summit '11
|
|
|
1
|
70302
|
Hardware kit, Summit Lid
|
|
|
2
|
66513
|
Logo plate, SS
|
Shop Now$14.99
|
|
2
|
66380
|
Lid assembly, SS, Summit 600 series
|
|
|
3
|
67089
|
Thermometer, C/F, Genesis II, export
|
|
|
4
|
67717
|
Bezel for Genesis/Summit, '07
|
|
|
5
|
70368
|
Spacers for handle, black, quantity 2
|
|
|
5
|
65908
|
Hardware pack for handle
|
|
|
5
|
70369
|
Handle with bezels/spacers/hardware, Summit 600 series
|
Shop Now$56.99
|
|
6
|
69274
|
Handle light (no batteries), Genesis/Summit
|
|
|
7
|
65576
|
Rotisserie motor, Type G '15
|
|
|
8
|
70888
|
Plastic latch w/spring
|
|
|
8
|
66339
|
Tuck away rotisserie bracket
|
|
|
9
|
70190
|
Warming rack, Summit 600 '07
|
Shop Now$62.99
|
|
10
|
70372
|
Rod-style grate, SS, 11.8", qty. 1
|
|
|
10
|
67552
|
Set of stainless steel grates, Summit 640/650/660/670
|
Shop Now$398.99
|
|
11
|
67670
|
Stainless steel flavorizer bars, full set, Summit 640/650/660/670
|
|
|
11
|
70375
|
Flavorizer bars, SS, set of 4
|
|
|
12
|
70308
|
Burner tube, Summit, export, quantity 1
|
|
|
13
|
62773
|
Hardware for table assembly, Genesis 300 series, '11
|
|
|
13
|
66285
|
LHS table assembly, SS, EU West
|
|
|
14
|
70312
|
LHS tool holder with hardware
|
|
|
15
|
79179
|
Manifold assembly 37mb, Summit E/S 670
|
|
|
15
|
88067
|
Manifold hardware, Summit '07
|
|
|
16
|
70882
|
Wiring harness, Summit 670
|
|
|
16
|
70189
|
Momentary light switch, Summit '11
|
Shop Now$22.99
|
|
17
|
88231
|
Hardware kit for control panel, Summit '11
|
|
|
17
|
66330
|
Control panel w/artwork, Summit 670, export
|
|
|
18
|
70883
|
Small bezel w/fasteners, Summit 470/670
|
|
|
18
|
88208
|
Hardware for bezels/control panel
|
|
|
19
|
70383
|
IR burner control knob, Summit export
|
|
|
20
|
91540
|
Lighted control knob assembly, '12, export
|
|
|
20
|
30134702
|
Control knob assembly, Summit LTD '08, export
|
|
|
21
|
88208
|
Hardware for bezels/control panel
|
|
|
21
|
70318
|
Bezel for main burners with hardware
|
|
|
22
|
30134602
|
Sear knob assembly, Summit '11, export
|
|
|
23
|
70880
|
Battery pack housing
|
|
|
23
|
70879
|
Battery pack head
|
|
|
24
|
88210
|
Hardware for burner tubes, Genesis/Summit '07
|
|
|
24
|
70874
|
Heat shield/water baffle, Summit 670
|
|
|
25
|
6498
|
Drip pan (qty 10) Large Grills
|
Shop Now$15.49
|
|
26
|
70113
|
Grease tray, Summit 600 '11, SS
|
|
|
27
|
70379
|
Catch pan kit
|
Shop Now$23.99
|
|
28
|
70324
|
Tank blocker, Summit 600 series
|
|
|
28
|
88063
|
Hardware for tank blocker
|
|
|
29
|
91357
|
Door magnet
|
Shop Now$7.99
|
|
29
|
66280
|
LHS door assembly, SS, S-600, export '17
|
|
|
30
|
70327
|
Door handles with hardware
|
Shop Now$57.99
|
|
31
|
91357
|
Door magnet
|
Shop Now$7.99
|
|
31
|
66273
|
RHS door assembly, SS, S-600, export '17
|
|
|
32
|
70981
|
LHS frame assembly, Summit '11, US
|
|
|
32
|
70332
|
Adjustable door hinge
|
|
|
33
|
67762
|
Hardware kit for bottom panel
|
|
|
33
|
91316
|
Bottom panel, Summit Platinum 6 burner NG, '10
|
|
|
34
|
67513
|
IR cover, Summit 6 burner, black
|
|
|
34
|
43291
|
IR Burner black plastic tubing/wire wrap, Summit '14
|
|
|
34
|
70392
|
Hardware for IR cover
|
|
|
35
|
70389
|
IR burner with bracket
|
|
|
35
|
70387
|
Orifice for IR, w/nut, 37 mb, Summit
|
|
|
36
|
70338
|
Cover box for IR burner
|
|
|
37
|
6021713
|
NUT M8 X 1 HEX BRASS
|
|
|
37
|
70390
|
Thermocouple with electrode and wire
|
|
|
38
|
6021713
|
NUT M8 X 1 HEX BRASS
|
|
|
38
|
70390
|
Thermocouple with electrode and wire
|
|
|
39
|
70398
|
Gas line for IR burner, 64"
|
|
|
40
|
84116
|
Rotisserie hardware for tuckaway rotisserie, w/forks, '10
|
|
|
40
|
80685
|
Rotisserie shaft w/handle, Summit E/S 600 series
|
|
|
40
|
70380
|
Screws for rotisserie forks, qty 4
|
|
|
40
|
89062
|
Handle for rotisserie shaft, Summit '11, export
|
|
|
41
|
70373
|
Rod-style grate, SS, 8.1", qty. 1
|
|
|
42
|
70381
|
Smoker box assembly
|
|
|
43
|
70187
|
Chipper grate, Summit '07 smoker
|
|
|
44
|
70310
|
Burner tube, Summit w/smoker, export, quantity 1
|
|
|
45
|
70041
|
Sear burner assembly, Summit 6 burner - export
|
|
|
46
|
67765
|
Hardware for side burner table, Genesis
|
|
|
46
|
91173
|
Side burner ring
|
|
|
46
|
30130201
|
Control knob for side burner, gray.
|
|
|
46
|
81252
|
Rubber lid bumper for side burner (Qty 1)
|
|
|
46
|
91175
|
Side burner cap, Summit '03
|
|
|
46
|
70394
|
LP side burner assembly, 37 mb, Summit export
|
|
|
46
|
91174
|
Ignition assembly for side burner
|
Shop Now$35.99
|
|
47
|
64849
|
Flavorizer bar brackets, Summit cookbox 6 burner
|
|
|
47
|
64847
|
Cookbox, Summit 660/670 '13
|
|
|
47
|
60600
|
Hardware for cookbox, Summit '10
|
|
|
47
|
70339
|
Silicone bumpers, quantity 4
|
|
|
48
|
88212
|
Hardware for bulkhead, Summit '07
|
|
|
48
|
70346
|
LP bulkhead assembly, Summit export
|
|
|
49
|
70309
|
Corrugated gas line, main, Summit
|
|
|
50
|
91470
|
LP hose and regulator 37 mb, 90 cm, UK
|
|
|
51
|
66463
|
Side burner lid w/hardware, Summit '17
|
|
|
51
|
67764
|
Hinge rod and clip for side burner lid, Genesis '07
|
|
|
52
|
66322
|
Side burner table assembly, SS '17
|
|
|
52
|
62773
|
Hardware for table assembly, Genesis 300 series, '11
|
|
|
52
|
88230
|
Hardware for side burner table, Summit '11
|
|
|
53
|
70349
|
RHS tool holder with hardware
|
|
|
54
|
70371
|
Transfer line for side burner
|
|
|
55
|
70351
|
Frame connector and hardware, Summit 6 burner
|
|
|
55
|
62776
|
Hardware for frame/rear panel, Genesis '11
|
|
|
56
|
70354
|
Rear panel, LP Summit 600 series
|
|
|
57
|
70332
|
Adjustable door hinge
|
|
|
57
|
70193
|
RHS frame assembly, Summit NG '11, EXP
|
|
|
58
|
70063
|
Tank hanger assembly w/bracket, Genesis - export
|
|
|
59
|
70063
|
Tank hanger assembly w/bracket, Genesis - export
|
|
|
60
|
88066
|
Tank glide buttons and hardware, export
|
|
|
61
|
81544
|
Match holder
|
|
|
62
|
70359
|
Caster w/o lock, Spirit ('09-'12), Genesis/Summit ('07-'11) qty 1
|
Shop Now$28.99
|
|
63
|
70360
|
Locking caster, Spirit ('09-'12), Genesis ('07-'11) Summit ('07-'11) qty 1
|
Shop Now$28.99
|
