A
|
55826
|
Operator's guide for Genesis Silver/Gold/Platinum LP, USA OBS
|
|
|
C
|
55860
|
Envelope for literature kits
|
|
|
A
|
55819
|
Assembly guide for Genesis Gold/Genesis Platinum, English
|
|
|
D
|
87004
|
Hardware pack for Genesis Gold B/C and Silver C. '05
|
|
|
1
|
88206
|
Hardware for lid assembly
|
|
|
2
|
78970
|
Self-threading nut
|
|
|
3
|
63201
|
Hardware for lid assembly for Genesis Gold/Platinum grills
|
|
|
3
|
60468
|
Logo, Genesis Gold, '05
|
|
|
3
|
60542
|
Lid assembly, Genesis B, mica black, SS handle
|
|
|
4
|
60149
|
Handle for `02 Genesis Gold/Platinum
|
|
|
5
|
80623
|
Warm-up basket, Genesis Gold/Plat, '10
|
Shop Now$43.99
|
|
6
|
80633
|
Warming rack, Silver/Gold/Plat B/C/Spirit 300 series
|
Shop Now$43.99
|
|
7
|
65619
|
Set of stamped stainless steel cooking grates
|
Shop Now$92.99
|
|
8
|
65903
|
Stainless steel flavorizer bars, Genesis Silver B/C (qty 5)
|
Shop Now$77.99
|
|
9
|
88203
|
Bottom tray rails w/hardware for Genesis Silver B/C
|
|
|
9
|
91079
|
Cookbox for Genesis Silver/Gold C, '04
|
|
|
10
|
1309
|
Hex nut 1/4 x 20 inch Keps nut
|
|
|
11
|
99250
|
Grease tray, Genesis/Spirit B/C, black
|
Shop Now$47.99
|
|
13
|
99253
|
Catch pan holder (packaged)
|
|
|
14
|
99238
|
LR/RF rail, qty 1
|
|
|
15
|
196
|
Hardware for trim pieces
|
|
|
16
|
60325
|
Left trim for Genesis Silver B/C, `04, boxed
|
|
|
17
|
99239
|
LF/RR rail, qty. 1
|
|
|
18
|
87403
|
1/4" Flat nylon washer, black
|
|
|
18
|
4086978
|
Hexhead bolt 1/4-20 x 2 1/4, black
|
|
|
19
|
90441
|
Galvanized hinge rod for Genesis A/B/C grills
|
|
|
19
|
70641
|
Hinge rod w/retainer clip
|
|
|
20
|
96015
|
Screw w/plastic washer, 10-16x3/4
|
|
|
22
|
70436
|
Hexhead bolt 1/4-20x1", black
|
|
|
23
|
87403
|
1/4" Flat nylon washer, black
|
|
|
24
|
60381
|
Caster frame assembly Genesis Silver B/C painted 2005
|
|
|
25
|
99240
|
Door plugs and bushings
|
|
|
26
|
99241
|
Caster w/insert
|
Shop Now$8.99
|
|
27
|
60427
|
Bottom Accessory Panel Genesis Silver C 2005
|
|
|
29
|
43849
|
Door handles w/screws, stainless steel
|
|
|
32
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
33
|
88206
|
Hardware for lid assembly
|
|
|
34
|
78970
|
Self-threading nut
|
|
|
35
|
63728
|
Hex head screw, 1/4-20x3.25
|
|
|
36
|
60470
|
Bezel replacement for Genesis Silver A/B/C, '05
|
|
|
37
|
60540
|
Thermometer, Q/Spirit/Genesis/Charcoal
|
Shop Now$15.99
|
|
38
|
67677
|
KNOB KIT MAIN 3/SEAR GEN A/B
|
|
|
38
|
87327
|
Control knob for Genesis Silver A/B/C, Gold B/C, `04
|
|
|
39
|
60337
|
Control panel for Genesis Silver/Gold B/C, `04, 270 degree
|
|
|
40
|
80802
|
Hardware for control panel, .250
|
|
|
41
|
87456
|
Discontinued - Rocker switch/bracket assembly
|
|
|
42
|
85865
|
Crossover tube for the center burner of Genesis Silver B/C, `02 Gold B/C grills
|
Shop Now$7.99
|
|
42
|
10409
|
Burner tube set, Genesis B/C, 05
|
Shop Now$71.99
|
|
43
|
10409
|
Burner tube set, Genesis B/C, 05
|
Shop Now$71.99
|
|
44
|
10409
|
Burner tube set, Genesis B/C, 05
|
Shop Now$71.99
|
|
45
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
46
|
60143
|
Manifold for 2002 Genesis Silver/Gold C, 270 degree sweep
|
|
|
46
|
65941
|
QCC1 hose and regulator, Gold, Platinum, Silver
|
Shop Now$45.99
|
|
47
|
93305
|
Aluminum catch pan kit
|
Shop Now$13.99
|
|
48
|
6415
|
Aluminum drip pans - small (10 pack)
|
Shop Now$10.49
|
|
49
|
87403
|
1/4" Flat nylon washer, black
|
|
|
49
|
82718
|
Hardware for tank scale
|
|
|
50
|
87896
|
Dual ground wire for side burner, Genesis C '04
|
|
|
50
|
905
|
Igniter, dual wire/piezo, '04
|
Shop Now$48.99
|
|
50
|
87898
|
Igniter/chamber w/black wire, Genesis C '04
|
|
|
50
|
87409
|
Dual piezo igniter for Genesis Silver/Gold side burner, `04
|
|
|
53
|
57575
|
Tank blocker assembly
|
|
|
54
|
96015
|
Screw w/plastic washer, 10-16x3/4
|
|
|
55
|
10311
|
Hardware kit for front panel assembly
|
|
|
56
|
99239
|
LF/RR rail, qty. 1
|
|
|
57
|
60343
|
Right trim for Genesis Silver/Gold C, `04, boxed
|
|
|
58
|
99238
|
LR/RF rail, qty 1
|
|
|
59
|
92177
|
Tank scale lock bracket
|
|
|
59
|
99243
|
Tank scale
|
|
|
59
|
87901
|
Wing nut 1/4-20 inch. Black.
|
|
|
60
|
90209
|
Bracket for right hand side swing up table. For Genesis-B and Genesis-C grills.
|
|
|
60
|
90441
|
Galvanized hinge rod for Genesis A/B/C grills
|
|
|
60
|
70641
|
Hinge rod w/retainer clip
|
|
|
61
|
99240
|
Door plugs and bushings
|
|
|
61
|
60560
|
Front panel replacement assembly, Genesis Silver C, Genesis Gold B/C, Genesis Platinu
|
|
|
62
|
96015
|
Screw w/plastic washer, 10-16x3/4
|
|
|
63
|
99378
|
RHS panel
|
|
|
64
|
80313
|
Tank glide buttons
|
|
|
65
|
60384
|
Wheel frame assembly, Genesis Silver/Gold B/C, '05
|
|
|
67
|
99240
|
Door plugs and bushings
|
|
|
68
|
42040
|
Match holder
|
|
|
69
|
99261
|
Hinge rod
|
|
|
410
|
55343
|
Instruction sheet for cast iron griddle
|
|
|
410
|
55396
|
Instruction sheet for dual piezo ignition system, `04
|
|
|
410
|
55354
|
Instruction Sheet QCC1 Hose Replacement
|
|
|
410
|
55819
|
Assembly guide for Genesis Gold/Genesis Platinum, English
|
|
|
410
|
50783
|
Instruction sheet. Fuel scale assembly.
|
|
|
410
|
55355
|
Instruction sheet for burner tube replacement, `02
|
|
|
470
|
10311
|
Hardware kit for front panel assembly
|
|
|
470
|
80425
|
Hardware for tank scale/panel
|
|
|
470
|
88203
|
Bottom tray rails w/hardware for Genesis Silver B/C
|
|
|
470
|
63201
|
Hardware for lid assembly for Genesis Gold/Platinum grills
|
|
|
470
|
82718
|
Hardware for tank scale
|
|
|
470
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
470
|
668
|
Control panel plugs with screws. 1/4-inch.
|
|
|
470
|
80313
|
Tank glide buttons
|
|
|
470
|
87004
|
Hardware pack for Genesis Gold B/C and Silver C. '05
|
|
|
480
|
10409
|
Burner tube set, Genesis B/C, 05
|
Shop Now$71.99
|
|
480
|
905
|
Igniter, dual wire/piezo, '04
|
Shop Now$48.99
|
|
485
|
87969
|
Hose guard. 72 inches long.
|
|
|
485
|
42140
|
Quick disconnect for natural gas hose, 3/8" (connector only)
|
|
|
485
|
872103
|
10-foot natural gas hose
|
|
|
485
|
63203
|
Hose guard. 36 inches long.
|
|
|
490
|
7639
|
Stainless steel rod cooking grates, 7mm, (Qty 2)
|
Shop Now$135.49
|
|
490
|
65906
|
Porcelain enameled steel cooking grates, (Qty 2)
|
Shop Now$56.99
|
|
490
|
7638
|
Porcelain enameled cast iron cooking grates, (Qty 2)
|
Shop Now$117.49
|
|
495
|
65903
|
Stainless steel flavorizer bars, Genesis Silver B/C (qty 5)
|
Shop Now$77.99
|
|
495
|
7536
|
Porcelain enameled flavorizer bars (qty 5)
|
Shop Now$65.99
|
|
510
|
7659
|
Rotisserie kit, Spirit II 200/300, US/MX/CA
|
Shop Now$134.49
|
|
510
|
80623
|
Warm-up basket, Genesis Gold/Plat, '10
|
Shop Now$43.99
|
|
515
|
87433
|
Trivet for side burner, Genesis Silver/Gold/Platinum
|
|
|
518
|
87345
|
Control knob for side burner, Genesis Silver/Gold C, `04
|
|
|
524
|
82747
|
Side burner lid, Genesis '05
|
|
|
525
|
42426
|
Screw, 10-32, phillips panhead, stainless steel
|
|
|
525
|
42427
|
Hex nut, 10-32 nylon-lock, stainless steel
|
|
