1
|
67063
|
Logo plate, SS w/black filling, Spirit II
|
|
|
2
|
69571
|
Lid assembly, Genesis II SX, SS
|
|
|
2
|
66061
|
Lid bumpers (qty 2)
|
Shop Now$11.99
|
|
2
|
66438
|
Lid hardware, Genesis/Searwood
|
|
|
3
|
66831
|
Handle bezel, Genesis II LX, '17
|
|
|
4
|
66417
|
Lid handle, Genesis II LX 340
|
|
|
5
|
69273
|
Handle light
|
Shop Now$40.49
|
|
6
|
66044
|
Warming rack, Genesis II E-310
|
|
|
7
|
66802
|
Set of cooking grates, SS, 7 mm, Genesis II LX 340
|
Shop Now$139.99
|
|
8
|
66795
|
Stainless steel flavorizer bars, Genesis II LX 340 (qty 5)
|
Shop Now$56.99
|
|
9
|
67489
|
Burner tube kit, Genesis II 3 burner LP
|
Shop Now$76.99
|
|
10
|
69320
|
Igniter electrode, black wire, 32"
|
|
|
10
|
69321
|
Igniter electrode, green wire, 42"
|
|
|
10
|
69319
|
Igniter electrode, yellow wire, 23"
|
|
|
10
|
69323
|
Igniter electrode, red wire, 28"
|
|
|
11
|
67454
|
Sear burner tube, Genesis '19
|
|
|
12
|
66685
|
Heat deflector, SS, Genesis II LX 340 (qty 3)
|
Shop Now$37.99
|
|
13
|
69284
|
Warming rack bracket set
|
|
|
14
|
66029
|
Burner tube clamp set, Genesis II E/SE series (qty 2)
|
|
|
15
|
69541
|
Thermocouple, Smart Grills
|
|
|
16
|
69574
|
Left side table assembly, Genesis EX/SX
|
|
|
16
|
69579
|
Hardware, fixed table, Genesis II EX/SX
|
|
|
16
|
68582
|
Hardware for fixed table, Genesis II '19
|
|
|
17
|
69568
|
Weber Connect Module, Smart Grills
|
|
|
17
|
69567
|
Weber Connect Module, bracket mount
|
|
|
18
|
69573
|
Cookbox, Genesis II EX/SX 335
|
|
|
18
|
66438
|
Lid hardware, Genesis/Searwood
|
|
|
18
|
66824
|
Hardware for cookbox, Genesis II/II LX
|
|
|
19
|
66357
|
Clip for ignition wire routing, round set (qty 2)
|
|
|
20
|
67459
|
LP Manifold assembly, Genesis II 330/335, '19
|
|
|
20
|
66822
|
Hardware, manifold, Genesis II LX
|
|
|
21
|
66028
|
Bottom tray rails, Genesis II E/SE series
|
|
|
22
|
66036
|
Grease tray, Genesis II E-310/340
|
|
|
23
|
69594
|
Left side panel, Genesis II EX/SX
|
|
|
24
|
66229
|
Top trim for control panel, SS, Genesis II/LX 300 series
|
|
|
25
|
69589
|
Control panel, Genesis II EX/SX 335
|
|
|
26
|
69283
|
Igniter/momentary switch, Genesis II '20
|
|
|
27
|
69317
|
Igniter button wire, 3 burner Genesis II
|
|
|
28
|
69565
|
Lighted control knob LED harness, Genesis II EX/SX
|
|
|
29
|
66753
|
Control knob kit, Genesis II LX (qty 3)
|
|
|
30
|
69599
|
Sear knob, red
|
|
|
31
|
69282
|
Light/momentary switch, Genesis/Summit
|
Shop Now$18.99
|
|
32
|
6415
|
Aluminum drip pans - small (10 pack)
|
Shop Now$10.49
|
|
33
|
93305
|
Aluminum catch pan kit
|
Shop Now$13.99
|
|
34
|
83320
|
Door magnet
|
|
|
34
|
69597
|
Mid-shelf, Genesis II EX/SX
|
|
|
35
|
69592
|
Bottom panel, Genesis II EX/SX
|
|
|
36
|
69584
|
Front frame assembly, Genesis II EX/SX
|
|
|
36
|
67693
|
Igniter wire conduit clamp, 3 pack
|
|
|
37
|
67066
|
Caster insert kit
|
|
|
37
|
67067
|
Casters (qty 2)
|
Shop Now$31.00
|
|
38
|
67442
|
LHS Door w/label, Genesis II 3 burner, '19, SS
|
|
|
39
|
67436
|
RHS Door, Genesis II 3 burner, '19, SS
|
|
|
40
|
69286
|
Door handle bezel set (qty 1)
|
|
|
41
|
69285
|
Door handle w/bezels (qty 1)
|
|
|
42
|
66438
|
Lid hardware, Genesis/Searwood
|
|
|
43
|
66401
|
Side burner lid, Genesis II LX series
|
|
|
44
|
66399
|
Side burner grate/trivet, Genesis II LX series
|
|
|
45
|
66400
|
Side burner cap
|
|
|
46
|
91173
|
Side burner ring
|
|
|
47
|
66397
|
Side burner tray, Genesis II LX series
|
|
|
48
|
68582
|
Hardware for fixed table, Genesis II '19
|
|
|
48
|
69579
|
Hardware, fixed table, Genesis II EX/SX
|
|
|
48
|
69576
|
Side burner and table assembly, Genesis II EX/SX
|
|
|
49
|
69312
|
Side burner igniter wires/electrode, Genesis II 330/335
|
|
|
50
|
67526
|
Valve/cup assembly for LP side burner, Genesis II, '19
|
|
|
51
|
66398
|
Control knob, side burner, Genesis II LX series
|
Shop Now$16.00
|
|
52
|
66396
|
Heat/water deflector, side burner, Genesis II LX series
|
|
|
52
|
67661
|
Wire clip w/adhesive for side burner/green wires
|
|
|
53
|
69590
|
Trim, rear frame, Genesis II EX/SX
|
|
|
54
|
69582
|
Rear frame assembly, Genesis II EX/SX
|
|
|
55
|
69591
|
Rear panel, Genesis II EX/SX
|
|
|
56
|
69595
|
Right side panel, Genesis II EX/SX LP
|
|
|
57
|
66232
|
Tank scale assembly
|
|
|
58
|
69549
|
Tank Scale Sensor, Smart Grills
|
|
|
59
|
69566
|
External battery shelf
|
|
|
60
|
69563
|
Genesis II EX/SX, controller board
|
|
|
61
|
69546
|
Battery housing, Weber Connect
|
|
|
62
|
69564
|
Cable kit, Genesis EX
|
|
|
63
|
69600
|
Hardware, tank glide buttons, Genesis II/2022 Genesis
|
|
|
64
|
69585
|
Rear tank panel, Genesis II EX/SX
|
|
|
64
|
66679
|
Hardware, tank panel buttons
|
|
|
65
|
66679
|
Hardware, tank panel buttons
|
|
|
65
|
69587
|
Front tank panel, Genesis II EX/SX
|
|
|
65
|
67161
|
Conduit tube for igniter wires, black
|
|
|
66
|
66834
|
Ground wire, blue, 28.25", Genesis II LX
|
|
|
66
|
69310
|
Igniter kit, Genesis II 330/335
|
|
|
67
|
67455
|
Main corrugated gas line, Genesis II, '19
|
|
|
68
|
66519
|
Side burner gas line w/QD fitting, Genesis II LX series
|
|
|
69
|
66518
|
Bulkhead assembly, Genesis II LX 240/340
|
|
|
70
|
67069
|
QCC1 Hose and Regulator, 21"
|
Shop Now$47.99
|
|
71
|
67059
|
Wheel insert kit
|
|
|
72
|
69602
|
8" Wheel w/insert, Genesis II EX/SX
|
|
|
73
|
66533
|
Match holder assembly, Genesis II LX 240/340
|
|
|
75
|
66251
|
Axle w/hardware, Genesis II E/SE series
|
|
|
76
|
40441903
|
LP literature kit, Genesis II EX/SX-335
|
|
|
76
|
68970
|
Meat probe w/red sleeve, SmokeFire
|
Shop Now$17.99
|
|
470
|
73437
|
Hardware bag H, tank panels LP, '19
|
|
|
470
|
75042
|
Hardware bag B, frame/tank scale, Genesis II EX/SX
|
|
|
470
|
73060
|
Hardware bag F, doors, Genesis II EX/SX
|
|
|
470
|
75036
|
Hardware Kit, Genesis II EX/SX LP
|
|
|
470
|
75077
|
Hardware bag G, table, Genesis II EX/SX
|
|
|
470
|
75043
|
Hardware bag D, trim/control panel, Genesis II EX/SX
|
|
|
470
|
73435
|
Hardware bag C, cookbox '19
|
|
|
470
|
75041
|
Hardware bag A, frame/wheels, Genesis II EX/SX
|
|
|
470
|
75045
|
Hardware bag E, igniter, Genesis II EX/SX
|
|
|
510
|
7652
|
Rotisserie, Genesis II/LX 200/300 series
|
Shop Now$145.49
|
|
510
|
7130
|
Premium grill cover, Genesis II/LX 300, Genesis E/S 300
|
|
|
510
|
7661
|
Weber Grill Light
|
Shop Now$40.49
|
|
510
|
7599
|
Griddle, Genesis II 300/400/600 series
|
Shop Now$118.99
|
|
510
|
8854
|
Sear grate, Genesis II/LX 300/400/600
|
Shop Now$66.99
|
